K2807
K2807
2807 brushless motor, KV 1300KV, for 7inch propellers, max thrust -, weight 53.4±1.5g（With wire）.
KV
1300KV KV
Weight
53.4±1.5g
Diameter
D32.9*20.1mm
Length
14±0.2mm
Features
Motor Model: 2807
Motor Size: D32.9*20.1mm
Shaft-D: Ф5 -0/-0.02mm
Shaft-L: 14±0.2mm
Wire Length: 200±5mm
Weight: 53.4±1.5g（With wire）
No Load Voltage: 10V
No load Current: 1.2±0.3A
No load Speed: 11875~13125RPM（1300KV）
Internal resistance: 72mΩ±5%
Working Voltage: 4-6S（3.7-4.2V/S）
KV Rating: 1300KV
Propeller: 7inch
Max Thrust: 2.2kg
Flight Weight: 3kg
Applications
FPV RacingFreestyleAerial Photography
